Roof shape and hall construction
SELECT steel building constructions offer extraordinarily wide scope with spans of up to 40.0 m, side heights of up to 12.0 m and snow loads of over 4.0 kN/m². Your steel building is designed according to your wishes - and customised precisely in terms of length, width, height and equipment.
Saddle roof
The most economical and therefore most common variant in hall construction are saddle roof halls. A roof pitch of 10° is ideal. Other roof pitches are possible on request.
Special features:
- generally optimal from a structural point of view and therefore the most cost-effective
- uncomplicated roof covering and sealing
- External drainage
- tension cable in the eaves to save material
Pent roof
Pent roof buildings are often chosen for visual reasons. This roof shape has particular advantages in combination with photovoltaic systems. With smaller spans and lower loads, a pent roof can also be the most cost-effective solution.
Special features:
- uncomplicated roof covering and waterproofing
- external drainage
- ideal for large photovoltaic systems when facing south
- less economical for wide halls
Multi-bayed saddle roof
SELECT steel buildings can also be designed with multiple bays to realise widths of over 40.0 m. The individual areas can be subdivided with partition walls if required.
Special features:
- very large hall complexes possible
- slender steel construction thanks to intermediate supports
- internal columns interrupt the usable area
- drainage via intermediate gutter in the roof valley
Flat roof
Thanks to a wide range of design options, modern flat-roofed halls are in demand not only for their functionality. Innovative flat roof constructions turn steel building constructions with flat roofs into architecturally appealing structures.
Special features:
- aesthetically pleasing
- roof greening possible
- roof structure with more complex waterproofing
- usually the most expensive variant
"Our primary goal is to offer you the most economical hall construction. Tell us your ideas - we will advise you individually and personally."
Simon Klein, one of over 70 space gain experts who are there for you at our 20 locations.
STAHLFLEX H-Hall and L-Hall - Flexibility with system
HALTEC works with two steel building constructions: H-hall and L-hall. The most economical hall construction always results from the right combination of length, width, height and the regional snow and wind loads. Depending on your requirements, one of the systems will optimise your desired hall, because saving on materials always means saving on costs. Only as much hall as necessary.
HALTEC. Secure space gain with hall systems.
We are an owner-managed company with our own production facilities in Germany. Continuous investment in our quality management guarantees product reliability and smooth processes in accordance with certified standards.
The win-win for your space gain: systematised project processes, systematised hall construction, systematised solution finding.
